| Brand Name : | MAX |
| Model Number : | MX-70 |
| Certification : | CE, ISO, SGS |
| Price : | Negotiation |
| Payment Terms : | Western Union, T/T, L/C/Paypal |
| Supply Ability : | 2000 set/month |
| Delivery Time : | 3-10 working days after received your payment |
Features:
1. Mould production with accurate grinding and heat treatment of worm and main rod, which is high accuracy, low comsumption and less noises.
2. Arm Reverse Function: Arm will be automatically reverse when it hits obstacles when closing.
3. Arm Swing Out Function: Arm will be swing out when vehicle hits the arm which can avoid further damage to the vehicle.
4. Cooling Fan Device: It will be automatically opened when the motor works in heavy duty and high temperature.
5. Manual Release Cluntch: When loss of power, it can manually open and close the barrier.
6. Sturdy Housing: 2mm thickness cold roll plate or galvanized plate with expoxy paiting, which can be heavy duty.
7. Anti-freezen oil can make our barrier gate working in -45 degree.
8. Spring sleeve can protect the accessories inside the machine case from damaging by spring broken.
9. Module production with all accessories, can be replced easily, and save cost.
10. Pressure spring can avoid damage casued by tention spring, which is more safety.
Specification
| Type | Model: MX-70 |
| Operation time | 1s,1.5s, 1.8s, 3s, 4s, 5s, 6s. Customized |
| Arm Type | Straight Arm: Max 6 meters, Size 45±100mm and 45*80 mm aluminum alloy Fence Arm: Two or three fence arm, Max 4.5 meters, aluminum alloy Folding Arm: 90 or 180 degree folding arm, max 5 meters, aluminum alloy |
| Material | Galvanized sheet or Cold roll sheets, 2mm thickness, can be heavy duty Coated with epoxy paint for weatherproof protection |
| Size | 320*280*935 mm |
| Spring And Bearing | Heat Treatment: more durable, more than 5 million times through operation testing |
| Rating Power | 80W |
| Rating Voltage | AC 220V/110V±10%, 50/60HZ |
| Remote Control Distance | less than 50 meters |
| Packing Size | 1020*375*467mm , strong carton case with cushion inside with air bubble film for protection |
| G.W | 55 KG |
| Delivery | By Sea: big order(more than 100 sets), Cheap, suggested If urgent, can be delivery by Airplane |
| Payment | Sample: full payment Order: usually 30%-40% advance deposite, balance before shipment |
| Advantages | 1. quick delivery time, 3-5 days for 50 sets after received advance deposite 2. 7 years OEM/ODM experience 3. quick response for handling problems |
| Application | Suitable for indoor as well as outdoor parking area at airport, shopping mall, warehouse,hotel, factories, condominium, car rental companies, etc. It can also be customized to beused together with any auto-pay ticketing parking or access control system |
